SS EASY BAND COATED
- Material: SS 316
-
Operating Temp: -80°C to +150°C
-
Coating: Black PPA – Thermoplastic or Polyester
-
Packing: 25 Mtrs (82.5 Ft.)/Roll in box
Features
Applications
SS EASY BAND COATED
Features
Ideal for bending & forming any shape pre punch holes make speedy and easy installation with use of nut & bolt
Coating material is non-toxic, halogen free, low smoke and UV resistant
Available in cardboard box as well as in plastic totes for easy to carry & use.
Applications
Applied where high vibration is the concern
SS EASY BAND COATED
| For Band Width (inch) | Width (mm) | Length L (mm) | Width W (mm) | Slot Width W1 (mm) | Slot Height H (mm) | SS Grade | Package Qty. per Box | G.wt. / Std. Pkg (100 Pcs.) Kgs | G.wt. / Std. Pkg (100 Pcs.) Lbs | Cat No. |
|---|---|---|---|---|---|---|---|---|---|---|
| 3/16 | 4.8 | 13.79 | 9.89 | 6.40 | 1.76 | SS 316 | 100 Pcs. | 0.15 | 0.33 | SBB-4 |
| 3/16 | 4.8 | 13.79 | 9.89 | 6.40 | 1.76 | SS 201 | 100 Pcs. | 0.15 | 0.33 | SBB-4/1 |
| 1/4 | 6.3 | 16.10 | 12.85 | 8.47 | 2.46 | SS 316 | 100 Pcs. | 0.23 | 0.50 | SBB-6 |
| 1/4 | 6.3 | 16.10 | 12.85 | 8.47 | 2.46 | SS 201 | 100 Pcs. | 0.23 | 0.50 | SBB-6/1 |
| 3/8 | 9.5 | 23.28 | 15.82 | 12.77 | 3.72 | SS 316 | 100 Pcs. | 0.84 | 1.85 | SBB-9 |
| 3/8 | 9.5 | 23.28 | 15.82 | 12.77 | 3.72 | SS 201 | 100 Pcs. | 0.84 | 1.85 | SBB-9/1 |
| 1/2 | 12.7 | 32.17 | 22.03 | 16.03 | 3.99 | SS 316 | 100 Pcs. | 1.03 | 2.26 | SBB-12 |
| 1/2 | 12.7 | 32.17 | 22.03 | 16.03 | 3.99 | SS 201 | 100 Pcs. | 1.03 | 2.26 | SBB-12/1 |
| 5/8 | 15.9 | 34.50 | 24.36 | 19.07 | 3.98 | SS 316 | 100 Pcs. | 1.17 | 2.57 | SBB-15 |
| 5/8 | 15.9 | 34.50 | 24.36 | 19.07 | 3.98 | SS 201 | 100 Pcs. | 1.17 | 2.57 | SBB-15/1 |
| 3/4 | 19.0 | 42.24 | 29.28 | 22.34 | 3.97 | SS 316 | 100 Pcs. | 1.28 | 2.82 | SBB-19 |
| 3/4 | 19.0 | 42.24 | 29.28 | 22.34 | 3.97 | SS 201 | 100 Pcs. | 1.28 | 2.82 | SBB-19/1 |
